Antenna Magus Professional 2019.2 version 9.2.0 | 1.5 Gb
Magus (Pty) Ltd. and CST - Computer Simulation Technology AG (CST) announce the release of Antenna Magus 2019.2, the latest version of the leading antenna design tool. Apart from fixes in the detected issues, this version hosts a couple of noteworthy enhancements as well.

[b
2019.2 - Release date: 10 May 2019[/b]
New Antennas, Tools, Libraries and Extensions
- Wire curl antenna. [MAGUS-18404]
- Microstrip to slotline transition. [MAGUS-26920]
- Square slotted dual-band patch antenna. [MAGUS-27155]
- Plano-convex hyperbolic lens. [MAGUS-27158]
- Positive meniscus elliptic lens. [MAGUS-27159]
- Traveling-wave series-fed patch array with inset-fed patch. [MAGUS-27163]
New Features, Extensions and Improvements
- Combline microstrip stub array design has been extended to design for 90 degree orientation of stubs. [MAGUS-27129]
- Anchor Points and Ports have been added to Connectors. [MAGUS-27077]
- Anchor Points in CST Studio Suite models have been update to be linked to Working Coordinate System (WCS). [MAGUS-27146]
- Automotive and Series-fed tags added to patch arrays. [MAGUS-27164]
Bug Fixes
- When exporting an Nx1 patch array to CST studio suite the history in some cases did not update correctly. [CST-53512]
- The bounding box position did not correctly position after resizing the application window. [AMB-2711]
- Bounding Box Values were not positioned correctly when returning from export mode. [AMB-2744]
- Error messages on design objectives disappeared in some workflows. [AMB-2747]
- In the Chart Tracer Tool with Auto mode selected the points re-adjusted when moving the anchor point. This behaviour should only happen in Anchor mode and has been fixed in Auto mode. [AMB-2776]
- When importing 2 traces into the Chart Tracing tool in Polar, the Chart Tracer switched the scale back to Linear if Log was selected first. [AMB-2777]
- Distance to reflective ground plane in Array Tool was not considered for Base Layouts. [AMB-2865]
- When Specifications have been disabled the automatic naming of tweaks did not match the numbering of the initial Design. [AMB-2876]
- The Array Layout selection did not show after duplicating a synthesized array. [AMB-2907]
- Reference impedances did not update correctly in the Compare Window.[AMB-2908]
- When exporting a distribution matrix from the Array tool multiple times, the second and all subsequent exports are in wavelengths, even if physical units were selected. [AMB-2921]
- The Export Macro did not handle index dependent variables correctly. [AMB-2922]
- In some design cases the error may have occurred: "Unable to add NearField monitor...". [AMB-2924]
- The Microstrip Line Tool may have become unresponsive for certain Objectives. [AMB-2932]
- The Dolph-Chebychev distribution taper is not suitable for large arrays with certain combinations of number of elements and side lobe levels. A warning message has been added for such cases. [AMB-2885]
- 3D previews for some devices did not update successfully. [AMB-2954]
- A Custom Template saved with Models without any description may have caused a crash when using or editing the Custom Template. [AMB-2956]
- Performance Estimation and 3D Preview of certain cases of the Printed conical log spiral antenna may have failed. [AMB-2694]
- The 3D Preview for reflectors may have failed to update if the blockage ratio was set to zero. [AMB-2959]
Antenna Magus is a software tool to help accelerate the antenna design and modelling process. It increases efficiency by helping the engineer to make a more informed choice of antenna element, providing a good starting design. Validated antenna models can be exported to CST MICROWAVE STUDIO from a huge antenna database which means that the engineer can get to the customisation phase of an antenna design quickly and reliably.
Antenna Magus has proven to be an invaluable aid to antenna design engineers and anyone who requires antenna models for antenna placement and/or electromagnetic interference studies.












MAGUS (Pty) Ltd. develops antenna design and information management software. Antennas designed using its software can be used in a wide variety of applications at various frequency bands, including, but not limited to, telecommunications, mobile devices, aerospace, satellite, automotive, radio astronomy and defense.
CST- Computer Simulation Technology AG founded in 1992, is a market leader in delivering 3D electromagnetic (EM) field simulation tools through a global network of sales and support staff and representatives. CST develops CST STUDIO SUITE, a package of highperformance software for the simulation of EM fields in all frequency bands. Its growing success is based on a combination of leading edge technology, a user-friendly interface and knowledgeable support staff. CST solutions are used by market leaders in a diverse range of industries, including aerospace, automotive, defense, electronics, healthcare and telecommunications. On September 30 2016 CST joined the SIMULIA brand of Dassault Systemes
Product: Antenna Magus
Version: 2019.2 (version 9.2.0) Professional
Supported Architectures: x64
Website Home Page :
Код:
www.antennamagus.com
Language: english
System Requirements: PC *
Supported Operating Systems: *
Software Prerequisites: CST Studio Suite 2019
Size: 1.5 Gb


Antenna Magus is built for: 64-bit systems running Windows VISTA Business, Windows 7 supporting Service pack 1, Windows 8, Windows 8.1, Windows 10 or Windows Server 2008/2012.
