3DCS Variation Analyst CAA V5 Based Software is used by manufacturers across the globe for Tolerance Analysis to reduce scrap, rework and warranty claims. 3DCS Variation Analyst CAA V5 Based (3DCS for V5) is an integrated software solution in CATIA V5 that simulates product assembly and part tolerance 3D stack-ups through Monte Carlo Analysis and High-Low-Mean (Sensitivity) Analysis.
Model Part and Process Variation - How does it work?
Use CATIA FTA - Embedded GD&T3DCS for V5 uses three methods of simulation; Monte Carlo Simulation, High-Low-Mean (Sensitivity analysis) and GeoFactor Analysis. These together highlight the sources of variation as well as potential build issues in the product.
By accurately modeling the build process, users can determine how their process will affect the assembly in addition to their part tolerance stack-up. This together essentially creates a virtual prototype that can be used to make decisions about design changes and tooling while reducing scrap and rework.
Compatibility: Creo 3.0-6.0Whats new:Read: "3DCS_Whats_New_v7600.pdf"
